STANDARD ALUMINUM CONDUCTOR STEEL REINFORCED
| Part # | AWG | STRAND CONFIGURATION | NO. OF STRANDS | STRAND DIAMETER | WT PER 1000 FT | CIRCULAR MILLS | RATED STRENGTH (LBS) |
|---|---|---|---|---|---|---|---|
| ASCR51 | 1/0 | Concentric | 7 | 0.1327″ | 145 | 105,656 | 4380 |
HIGH STRENGTH ALUMINUM CONDUCTOR STEEL REINFORCED
| Part # | AWG | STRAND CONFIGURATION | NO. OF STRANDS | STRAND DIAMETER | WT PER 1000 FT | CIRCULAR MILLS | RATED STRENGTH (LBS) |
|---|---|---|---|---|---|---|---|
| ACSR52H | 1/0 | Concentric | 19 | 00961″ | 277 | 110,823 | 11,300 |
| ACSR55H | Class II | Concentric | 19 | 0.1327″ | 527 | 211,311 | 28,400 |
Other sizes and configurations of Aluminum and Aluminum Steel Reinforced conductors are available. Please contact our sales department for your specific need.
